منبع تغذیه : باتری
|
مشخصه ها |
گستره و تلرانس |
|
|
Inductance (H) |
20uH~2000H | ±(0.5%+5) |
|
Capacitance (F) |
200pF~20mF |
±(0.5%+5) |
| Resistance (Ω) | 20Ω~200MΩ |
±(0.3%+5) |
| Test frequency (Hz) |
100Hz/120Hz/1kHz/10kHz/ 100kHz |
√ |
| Operating voltage | 0.6Vrms |
√ |
| Test parameters | L/C/R/DCR/Q/D/θ/ESR |
√ |
| Features | Range | |
| Display count |
20000 |
|
| D/Q display count |
2000 |
|
| D/Q resolution |
0.001 |
√ |
| Auto range |
√ |
|
| Test frequency real-time display |
√ |
|
| Measurement mode |
Series/Parallel |
√ |
| Auto power off |
√ |
|
| Low battery indication |
≤6.8V |
√ |
| Data hold |
√ |
|
|
Relative mode |
√ |
|
| USB interface |
√ |
|
| USB interface/PC data records |
60000 |
|
| Data storage |
--- |
|
| LCD backlight |
√ |
|
| Analog bar graph |
26 |
|
| Deviation ratio measurement |
√ |
|
| Comparison function |
√ |
|
| Calibration function |
√ |
|
| Output impedance | 120Ω |
√ |
| Auto LCR check and measurement |
√ |
|
| مشخصههای کلی | |
| توان | 9V battery (6F22) or USB |
| نمایشگر | 40mm x 63mm |
| ابعاد | 96mm x 193mm x 47mm |
| متعلقات | SMD test clamp, USB interface cable, multi-purpose socket, PC software CD |
| Optional accessory | USB power adaptor |
Packing List:
1*UT612 LCR meter
1*PC software CD
1*English manual
1*SMD test clamp
1*Multi-Purpose socket
1*Color box
1*Carry box
