Oscilloscoop function
Bandwidth	40 / 70 MHz
channels	2
Sample rate	250 MSa/s (single channel), 125 MSa/s (double channel)
A/D converter	8 bit
Memory depth	6k (1-channel), 3k per channel (2-channels)
Vertical scale	10 mV/div - 10V/div
Function generator
Frequency	Sinus(1Hz - 25MHz), Block(1Hz - 10 MHz), Ramp(1Hz - 1 MHz), EXP(1Hz - 5 MHz)
Sampling	250 MSa/s
Amplitude	2.5 Vpp (50Ω), 5 Vpp (high-impedance)
Resolution	0.10 %
Output impedance	50 Ω
Multimeter function
Resolution	4000 counts
AC voltage	1 mV - 600 V
DC voltage	100 µV - 600 V
AC current	10 µA - 10 A
DC current	10 µA - 10 A
Resistance	0.1 Ω - 40 MΩ
Capacity	10 pF - 100 µF
Diode	0 V - 2 V
Input impedance	10 M Ω
Other specifications
Display	2,8 Inch TFT (320x240)
Battery	2 x 2600mA
