| Characteristic | Specification |
|---|---|
| Insulation Resistance | 100MΩ Min at 500VDC |
| Dielectric Strength Between Open Contacts | 1500VAC (for one minute) |
| Between Contacts and Coil | 1500VAC/2500VAC (for one minute) |
| Operate Time | 15ms |
| Release Time | 10ms |
| Temperature Range | -40°C to +70°C (Class F: 85°C) |
| Shock Resistance — Operating Extremes | 10G |
| Shock Resistance — Damage Limits | 100G |
| Vibration Resistance | 10-55Hz, 1.5mm |
| Max. Switching Frequency — Mechanical | 18,000 operations/hr |
| Max. Switching Frequency — Electrical | 1,800 operations/hr |
| Humidity | 40-85% |
| Weight | Approx 36g |
