| Characteristic | Specification |
|---|---|
| Insulation Resistance | 100MΩ Min at 500VDC |
| Dielectric Strength Between Open Contacts | 750VAC (50/60Hz for one minute) |
| Between Contacts and Coil | 1500VAC (50/60Hz for one minute) |
| Operate Time | 10ms |
| Release Time | 5ms |
| Temperature Range | -40°C to +85°C / 105°C |
| Shock Resistance — Operating Extremes | 10G |
| Shock Resistance — Damage Limits | 100G |
| Vibration Resistance | 10-55Hz, 1.5mm |
| Max. Switching Frequency — Mechanical | 18,000 operations/hr |
| Max. Switching Frequency — Electrical | 1,800 operations/hr |
| Humidity | 40-85% |
| Weight | Approx 10g |
| Safety Standard | UL, TUV, RoHS |
